觸點型式Contact type
|
一組常閉A group of normally closed
|
|
觸點材料Contact material
|
銀合金Ag alloy
|
|
接觸電阻Contact resistance
|
2mΩ Max(1A 24VDC)
|
|
觸點負載Contact load
|
60A 250VAC 80A 250VAC
|
|
切換電流上限Max switching current
|
60A 80A
|
|
切換電壓上限Max switching voltage
|
250VAC 250VAC
|
|
切換功率上限Max switching power
|
15000VA 20000VA
|
|
短路電流上限Max switching voltage
|
1800A 10ms 2400A 10ms
|
|
吸合時間Response time
|
20ms Max
|
|
|
釋放時間Release time
|
20ms Max
|
|
|
絕緣電阻lnsulation resistance
|
100MΩ Min.(DC500V)
|
|
|
介質耐壓Dielectric withstanding voltage
|
觸點與觸點間between contacts:AC 1500VAC,50/60Hz 1Min
|
|
|
觸點與線圈間between contacts＆coil:AC 4000VAC,50/60Hz 1min
|
||
|
抗振動Vibration resistance
|
耐久Durable
|
10～55Hz,雙振幅1.5mm
|
|
誤動作False action
|
10～55Hz,雙振幅1.5mm
|
|
|
抗沖擊lmpact resistance
|
耐久Durable
|
10G Min.
|
|
誤動作False action
|
50G Min.
|
|
|
壽命Life times
|
機械壽命Mechanical life
|
100,000cycles
|
|
電氣壽命Electrical life
|
10,000cycles
|
|
|
環境溫度Ambient temperature
|
-30℃～+70℃(不冷凝)No condensation
|
|
|
重量Weight
|
不帶附件約33g Without attachment to about 33g
|
|
